- OPENING WIDTH: 71” OR GREATER
- MAX PANEL SIZE: 5 x 10
- USAGE: HIGH FREQUENCY
- OVERLAP: 3” PANEL OVERLAP
- CLEARANCE: APPROX. 45%
Details
DESIGNING WITH BYPASS DOORS
Elevate your interior space with Raydoor sliding bypass doors, crafted to be both an elegant feature and a highly functional design solution. With a range of customizable finishes and inserts, these doors can blend effortlessly with your aesthetic while enabling more versatile, reconfigurable, and user-friendly space. From small closets, to pantries, to large rooms, bypass doors exemplify timeless, versatile simplicity in design.
Highlights
- Cost Effective: Elegant and simplistic by design, bypass doors also are a great cost friendly choice.
- Simple Installation: With a streamlined installation process and smooth, effortless operation, bypass sliding doors are perfect for both builders and users.
- Modern Design: Our trackless design creates a modern look
- Versatile Applications: Bypass door systems are a simple and reasonably priced method of dividing whole rooms or simply closing off storage space.
What's Included:
Choice of Frame and Finish
Grey Floor
Guide
Soft-Close
Track
System Types
Find CAD/Revit files, system drawings, spec sheets, and other resources for our sliding bypass door solutions.
Optional Hardware
Each system is equipped with our signature soft-close track. Optional upgrades including hardware, locks and specialty operating mechanisms are listed below. If a feature is incompatible with a system, it will be greyed out.
Handles & Pulls
Round Pull
Brushed Metal
Rectangular Pull
Brushed Metal
Oblong Pull
Brushed Metal
ADA Pull
Brushed Metal
Round Pull
Black
Rectangular Pull
Black
Oblong Pull
Black
ADA Pull
Black
Door locks
Flush Thumb Turn/Coin
Brushed Metal
Flush Lock
Thumb/Key
Brushed Metal
Floor Strike
Brushed Metal
Thumb Key
Brushed Metal
Flush Bolt
Brushed Metal
ADA Thumb Turn
Brushed Metal
Flush Thumb Turn/Coin
Black
Flush Lock
Thumb/Key
Black
Floor Strike
Black
Thumb Key
Black
Flush Bolt
Black
Specialty Hardware
Acoustic
Solutions
Giro Door
Connector
Dust-Proof
Strike
Floor Track
Unavailable in this system
Jamb Lock
Straight Bolt
Roller Latch
Wall Mount
Edge Pull
FREQUENTLY ASKED QUESTIONS
Still looking for answers? Take a look at our answers regarding our bypass sliding door solutions below, or visit our FAQ page for more details.
How much of an opening can you access with bypass doors?
Raydoor’s bypass system has an approximate 45% clearance, meaning the panels overlap as they slide and a portion of the opening remains covered. The exact usable opening depends on the number of panels, their widths, and the system configuration.
How does a bypass sliding door system work?
A bypass sliding door system uses two or more panels that slide past one another along parallel tracks. This configuration allows panels to overlap as they open, making it a practical solution for closets, pantries, and room dividers where space is limited.
What is the difference between a bypass sliding door and a single sliding door?
A single sliding door moves one panel alongside an opening, while a bypass system uses multiple panels that slide past one another. Bypass doors are useful when you want to cover a wider opening or need multiple panels, while a single sliding door is often suitable for a standard doorway.
How many panels can a Raydoor bypass system have?
Raydoor offers bypass configurations with two, three, four, and five panels, including a four-panel symmetrical option. The best configuration depends on the width of the opening, desired access, and how you want the panels to move.
What is the minimum opening width for a Raydoor bypass door system?
Raydoor’s bypass sliding door system is designed for openings 71 inches or wider. The appropriate configuration depends on the opening dimensions and number of panels selected.
Do Raydoor bypass doors require floor tracks?
Raydoor’s standard bypass system uses a top-mounted track and floor guide rather than a continuous track across the floor. This creates a cleaner floor transition while helping guide and stabilize the moving panels.
INTRODUCING GLASS BYPASS DOORS
A leading option for sliding door systems since 2000, our patented TwinFrame® panel design features sleek and versatile dual-layer glazing. Available in acrylic or other resins, TwinFrame is known for offering designers a durable, lightweight solution with excellent optical clarity and superior impact resistance.
Our newest evolution of TwinFrame construction, RAYDOOR Glass™, integrates the classic beauty and practicality of glass while maintaining our innovative design practices. Sliding bypass glass door systems are perfectly suited for projects that demand the unique visual effect of glass, in addition to its practical properties like enhanced scratch resistance and better sound insulation.
